UHMWPE Fiber
At present, UHMWPE fiber is the fiber with the highest specific strength and specific modulus in the world. It is spun from polyethylene with molecular weight of 1 million ~ 5 million.
Excellent Team
We also have a very excellent team with professinal experiences for global purchasing. One of our competitive service is purchase agent service.
Our Service
Doshine adheres to the business philosophy of quality, innovation and service, strict manufacturing process, reliable performance quality, and mature manufacturing process technology.
Quick Response
We will reply you within 12 hours after receiving theinquiry.Tell us what you need. We have R&D team with abilities for new product customization.
Competitive Price
We can help customer search any product in China or Asia to get the best quality with lower cost. We will try our best to let you get a more efficient procurement.
Definition of UHMWPE Fiber
UHMWPE Fiber is a linear polyethylene with molecular weight usually between 2 and 6 million. The fracture toughness, low friction coefficient, high impact strength, and low density of UHMWPE Fiber have made it a popular choice as the articulating surfaces of joint replacements, such as hip, knee, ankle, and shoulder. Although UHMWPE Fiber possesses numerous attractive bulk and surface properties, these properties can be compromised by the presence of long-term radicals in the bulk resulting from the ionizing radiation employed in the sterilization process. These radicals can interact with oxygen, leading to the generation of oxygen containing functional groups and deterioration of the surface and bulk properties, particularly the rate of production of particles during the wear process. An overproduction of wear debris has been linked to the inflammatory reaction in the tissues adjacent to the implant. This adverse tissue response will lead to granulomatous lesions, osteolysis, bone resorption, and implant failure.
Benefits of UHMWPE Fiber
Polyethylene is the most commonly used plastic in the world, but how do you know if it's the right yarn for your application? Consider the attributes of ultra-high-molecular-weight polyethylene (UHMWPE) - a very tough subset of polyethylene that has a strength to weight ratio 8-15 times greater than steel. UHMWPE Fiber has a diverse range of uses from manufacturing to medical as well as in wire and cable applications. This is due to its long list of benefits which meet specific requirements for many different jobs.
→Low specific gravity – will float in water.
Excellent resistance to stress and high resistant to cracking.
Abrasion wear resistance – 15 times more resistant to abrasion than carbon steel.
Its 40% Stronger than Aramid yarns.
Its strong chemical resistance - highly resilient to most alkalis and acid, organic solvents, degreasing agents and electrolytic attack.
It's non-toxic.
Excellent dielectric properties.
Self-lubricating – very low coefficient of friction (comparable to PTFE).
Non-staining.
FDA approved for use in food and medical applications.
What Are The Uses Of UHMWPE Fibers
UHMWPE (Ultra-high molecular weight polyethylene) is a type of high-performance synthetic fiber that is widely used in various applications. With its excellent strength, high modulus, and high impact resistance, UHMWPE fiber has become one of the most popular materials in the world of textile engineering. In this article, we will take a close look at the uses of UHMWPE fibers and how they are benefiting various industries.
Ballistic protection
Perhaps the most widely recognized application of UHMWPE fiber is in ballistic protection. The high tensile strength and low density of UHMWPE fibers make them an ideal material for bulletproof vests, helmets, and other protective gear. In fact, due to its proven effectiveness, UHMWPE fiber has become the material of choice for many military and law enforcement agencies worldwide. Compared to traditional materials such as Kevlar, UHMWPE fiber is much lighter, thinner, and more comfortable to wear, making it an ideal solution for body armor.
Aerospace industry
Another major application of UHMWPE fiber is in the aerospace industry. The excellent strength, stiffness, and corrosion resistance of UHMWPE fibers make them ideal for use in spacecraft components such as cables, tethers, and radiation shielding. UHMWPE fiber ropes have also been used in various space missions, including the Mars Pathfinder, Galileo, and Cassini missions.
Marine industry
UHMWPE fiber's resistance to water, chemicals, and UV radiation make it an ideal material for the marine industry. UHMWPE ropes are used in various applications, such as mooring, towing, and lifting operations. UHMWPE fiber is also used in the manufacture of fishing lines and nets, due to its high abrasion resistance and low stretch characteristics.
Medical applications
UHMWPE fibers have also found their way into the medical industry. UHMWPE fiber is used to manufacture orthopedic implants, such as knee and hip replacements. The biocompatibility and low wear rate of UHMWPE fibers make them an ideal material for medical applications, where durability and longevity are essential.
Sporting goods
UHMWPE fibers are used to manufacture various sporting goods due to their strength and low weight. For example, UHMWPE fibers are used in the manufacture of tennis strings, badminton strings, and bowstrings. UHMWPE fibers are also used in the manufacture of racing sails, due to their low weight and high strength-to-weight ratio.
Industrial applications
UHMWPE fibers have many applications in the industrial sector. UHMWPE fiber is used in the manufacture of conveyor belts, slings, and ropes. The low coefficient of friction and high wear resistance of UHMWPE fibers make them ideal for these applications. UHMWPE fibers are also used in the manufacture of high-performance industrial filters, due to their high-intensity performance and chemical resistance.
UHMWPE Fiber and UHMW (Ultra-High Molecular Weight) are both high-performance polymers known for their exceptional wear resistance, impact strength, and low coefficient of friction. While both UHMWPE and UHMW share some common properties, UHMWPE Fiber is a more specialized and higher-performing polymer that is typically used in more demanding applications. However, there are some differences between the two materials:
Chemical Structure: UHMWPE Fiber is a subset of UHMW and is a type of polyethylene with extremely long molecular chains. In contrast, UHMW is a general term used to describe polymers with a molecular weight greater than one million.
Strength and Toughness: UHMWPE Fiber is stronger and tougher than UHMW, with a tensile strength of up to 6000 psi and an impact strength of 160 ft-lbs/in. UHMW, on the other hand, has a tensile strength of around 3100 psi and an impact strength of around 75 ft-lbs/in.
Applications: UHMWPE Fiber is commonly used in applications where high strength and impact resistance are required, such as ballistic armor, medical implants, and aerospace components. UHMW is often used in applications where low friction and wear resistance are important, such as conveyor components, bushings, and bearings.
Is UHMWPE Fiber stronger than HDPE
UHMWPE Fiber is stronger than HDPE (High Density Polyethylene). This is because UHMWPE has longer polymer chains, which give it greater tensile strength, impact resistance, and overall toughness compared to HDPE.
Specifically, UHMWPE Fiber has a tensile strength of up to 6000 psi, whereas HDPE typically has a tensile strength of around 4000-5000 psi. UHMWPE also has a higher impact strength, meaning it is better able to withstand sudden shocks or impacts without breaking. Additionally, UHMWPE has a lower coefficient of friction and better abrasion resistance compared to HDPE.
Due to its superior mechanical properties, UHMWPE Fiber is often used in demanding applications where high strength and durability are required, such as in ballistic armor, medical implants, and aerospace components. HDPE, on the other hand, is typically used in more general-purpose applications such as packaging, pipes, and household products.
Study of UHMWPE Fiber Surface Modification
Ultra-high molecular weight polyethylene (UHMWPE)/epoxy composites with excellent adhesive properties were prepared by forming an interface membrane on the UHMWPE fiber surface. The interface membrane of the UHMWPE fiber and epoxy resin was polymerized by an aldol condensation between polyvinyl alcohol (PVA) and glutaraldehyde. Different surface treatment methods of UHMWPE fibers were optimized and the two-step PVA-glutaraldehyde condensation (Corona-PG-2S) method is the best.
The interfacial adhesion between UHMWPE fiber and epoxy resin was enhanced, and the adhesive properties of the composite were improved. X-ray photoelectron spectroscopy (XPS) and energy dispersive spectrum (EDS) results of the fiber treated by Corona-PG-2S shows that the surface oxygen content was up to 25.0 wt %, with an increase of 17.3 wt % compared with the surface oxygen content of unmodified UHMWPE fiber, which indicated that the surface polarity was greatly enhanced. The adhesive properties were improved by improving the polarity of the surface.
The peel strength, ultimate cohesive force, tensile strength and flexural strength of the composite treated by Corona-PG-2S were greatly increased to 262.8%, 166.9%, 139.7%, 200.6% compared with those of unmodified samples. The composite prepared by Corona-PG-2S had excellent adhesive properties, demonstrating that the Corona-PG-2S method plays a major role in significantly improving the composite adhesive properties.
Ultra-high molecular weight UHMWPE Fiber is known to degrade during natural (shelf) aging following gamma irradiation in air, but the mechanical signature of degradation remains poorly understood. Accelerated aging methods have been developed to reproduce the natural aging process as well as to precondition total joint replacement components prior to joint simulator wear testing.
To determine the spatial variation of mechanical properties within each insert, miniature disk shaped specimens were machined from the surface and subsurface regions of the inserts. Analysis of variance of the test data showed that aging significantly affected the small punch test measures of elastic modulus, initial load, ultimate load, ultimate displacement, and work to failure. The accelerated aging protocol was unable to reproduce the spatial mechanical profile seen in shelf aged components, but it did mechanically degrade the surface of GUR 1120 tibial components to an extent comparable to that seen after 10 years of natural aging.
Test specimens showed a fracture morphology consistent with the decreased ductility and toughness which was corroborated by the small punch test metrics of this study. Our data support the hypothesis that UHMWPE Fiber undergoes a spatially nonuniform change towards a less ductile mechanical behavior after gamma irradiation in air and shelf aging.
How Do You Differentiate UHMWPE Fiber from HDPE
There are three tests you can perform:
Burn Test
light it with a match and smell the smoke. If it smells like candle wax – that indicates polyethylene. UHMW does not drip as readily as HDPE but it will drip.
Oven Test
place it in an aluminum dish in a 300 degree oven. Regular HDPE will slump or melt but UHMWPE fiber will not change size or shape. However, it could warp or distort due to built in stresses.
Saw Test
When cut with a saw, regular HDPE gives sawdust or filings while UHMW gives strings or nothing.
HDPE vs UHMWPE Fiber – Is One Better Other
HDPE and UHMW fiber have many similar qualities, being that both are made of ethylene monomers. Choosing between them will depend on your specific needs and which material most effectively addresses those needs.
HDPE plastic is one of the most popular plastic materials. It is lighter than UHMW fiber, which may be beneficial in applications looking to keep weight and costs low. It is generally easier to machine and less costly to produce than UHMW fiber, making it one of the most common plastics. HDPE is often used for storage containers, tanks, and more.
UHMW is better suited for applications involving high-wear and heavy contact. It holds up much better than HDPE against friction and wear. For demanding applications with high-stress or harsh conditions, UHMW may be a more reliable option. UHMWPE fiber is a cost-effective material often used as mated parts, wear parts, or even padding in machines.
Both materials are useful in a variety of instances. HDPE is often best used for items that need to be shaped using techniques like welding or 3D printing, especially in tanks or vessels that need to hold chemicals or other fluids. Meanwhile, UHMWPE fiber tends to be better suited for industrial or manufacturing applications where friction or wear may be a concern.
JIAXING DOSHINE NEW MATERIAL CO., LTD. is the leading global supplier of various high performance materials. We are mainly supplying carbon fiber prducts (chopped strands, veil, cloth, and other related products), aramid fiber products, basalt fiber products, and other new materials.
These products are widely used in automobile parts, pressure vessel, hull, sports equipment, medical equipment, sound trough, friction and seal material.
2012, Doshine(Hongkong) company established, and we have our first team to service our customers which have been exporting various of materials to the oversea markets.
We also can supply a wide range of products to meet ever-changing market demands. Customized orders are welcomed. Trust us, and we will try our best to let you get a more efficient procurement.
